ICP Heat Pump manuals at InspectApedia.comICP Manuals, Parts Lists, Wiring Diagrams

for International Comfort Products - OR -
for ICP Inter-City Products Corporation Contact & Manuals

Manuals, parts lists, wiring diagrams for HVAC equipment: free downloads as PDF files, for ICP or International Comfort Products HVAC equipoment, plus company contact information.

Here we provide free downloadable copies of installation and service manuals for heating, heat pump, and air conditioning equipment, or contact information for the manufacturers who can provide that information for nearly all major brands of HVAC equipment.

We include links to contact information for each manufacturer or producer of these air conditioners, heat pumps, furnaces, boilers and related equipment, parts, and installation, repair, wiring diagrams, manuals.

We include immediate downloads of example installation & repair manuals and wiring diagrams for air conditioners, heat pumps, and heating equipment from a variety of manufacturers as well as contact information to obtain the exact manual or wiring diagram for your unit.

InspectAPedia tolerates no conflicts of interest. We have no relationship with advertisers, products, or services discussed at this website.

- Daniel Friedman, Publisher/Editor/Author - See WHO ARE WE?

ICP International Comfort Products Contact Information / Manuals

ICP Unitary 2-ton Air Handler with hot water coil AXH series cited at InspectApedia.com

Shown here, an International Comfort Products ICP UNITARY 2T Air Handler W/ Hot Water Coil model No. AHXW32400A for sale in 2021.

ICP International Comfort Products, itself a Carrier HVAC brand, owns or distrubutes Arcoaire, Comfortmaker, Day&Night, Heil, KeepRite and Tempstar HVAC equipment.

Article Contents

...

ICP International Comfort Products Co. Contact Information

  • Contact: ICP International Comfort Products, International Comfort Product, LLC PO Box 128, Lewisburg, TN 37091 USA

    USA: International Comfort Products Corporation (USA)  650 Heil--Quaker Avenue P.O. Box 128  Lewisburg, Tennessee 37091  (931--270--4100)
    CANADA: International Comfort Products division of UTC Canada Corporation  6060 Burnside Court, Unit 1, Mississauga, Ontario L5T 2T5
    (905--795--8113).

    Manufacturers of Airquest, Arcoaire, Clare, Comfortmaker, Dettson, Heil, Keeprite, Lincoln, Tempstar and other quality brand name private label products
  • Contact: Intertek, UTC Canada Corporation, ICP Division, 3400 Industrial Boulevard Sherbrooke, Quebec - Canada

    US: International Comfort Products 650 Heil-Quaker Avenue P.O. Box 128 Lewisburg, Tennessee 37091 (931) 270-4100

    Canada: International Comfort Products Division of Carrier Canada Corporation 6060 Burnside Court, Unit 1 Mississauga, Ontario L5T 2T5 (905) 795-8113

Note that some ICP documents like the oil furnace warranty listed below (2021) carry the parent or Carrier HVAC brand.

"Manufacturers of Airquest, Arcoaire, Comfortmaker, Day & Night, Heil, ICP Commercial, Keeprite, Tempstar and other quality brand name private label products."

ICP, International Comfort Products website: http://www.icpusa.com/

ICP is in turn, is part of

UTC Climate, Controls & Security at https://www.ccs.utc.com/ccs/en/worldwide/contact-us/

UTC in turn is a unit of

United Technologies Corp. that you can also contact at: UNITED TECHNOLOGIES UTC Climate Controls & Security

Also see these ICP brands and equipment information sources:

Also see

ICP Manuals other than those given at the links just above:

...

ICP HVAC Product Label Information

ICP HVAC equipment like the indoor air handler or outdoor compressor-condenser unit is identified by a product data tag or sticker that contains information about the unit.

The data tag will include two key identification fields: the product designation or identification code and the product's individual serial number.

ICP Product Designation Codes

The product designation or model identification code is a character string that provides information about the product type, features and capacity.

ICP Product Number Identification Guide at InspectApedia.com

[Click to enlarge any image]

See more details in this

ICP Product Serial Number & equipment age

The product serial number is a unique character string including numbers that can be decoded to give the product's age and manufacturing details.

ICP HVAC Age Decoder

ICP HVAC equipment manufacturing date is usually encoded in the serial number


YYWW567890

or in the serial number format

XYYWW56790

(ignore the first alphabetic character, pick up the first four numeric digits, and decode them as YYWW as we illustrate here.

Use the first four numeric digits that form YYWW where YY is year of manufacture and WW is week of manufacture in that year.

The remaining numeric digits, usually 5, form a unique serial numer or manufacturing sequence number of the equipment.

This same manufacturing date encoding appears in most HVAC equipment distributed under the ICP brands of:

Arcoaire, Comfortmaker, Heil, ICP, International Comfort Products, Inter-City Products, Keeprite, Tempstar, and UTC, United Technologies Inc.,

...

ICP International Comfort Products HVAC Manuals, also Heil & Tempstar

  • ICP Tempstar Heil 9MPT / 9MPV A1 A2 CONDENSING GAS FURNACE INSTALLATION MANUAL [PDF] (2001) International Comfort Products Corporation (USA), Lewisburg, TN USA 37091
  • ICP Tempstar Heil 9MPT / 9MPV A1 A2 CONDENSING GAS FURNACE SERVICE MANUAL [PDF] (2001) International Comfort Products
  • ICP DLC4 (A/H) DUCTLESS SPLIT SYSTEM A/C & HEAT PUMP OWNER'S MANUAL [PDF] (2012) R−410A Ductless Split System Air Conditioner and Heat Pump Models: DLC4(A/H)−Outdoor Unit, DLF4(A/H)−Indoor Unit Sizes: 9K, 12K, 18K, 24K, 30K and 36K ICP, International Comfort Products, LLC
  • ICP DLC4 (A/H) DUCTLESS SPLIT SYSTEM A/C & HEAT PUMP SERVICE MANUAL [PDF] (2013) ICP, SERVICE MANUAL R−410A Ductless Split System Air Conditioner and Heat Pump MODELS: DLC4(A/H)−Outdoor, DLF4(A/H)−Indoor SIZES: 9K, 12K, 18K, 24K, 30K, and 36K

    Includes ICP DLC unit error codes beginning on p. 48
  • ICP DLFCAB / DLFCHB / DLFDAB / DLFDHB DUCTLESS HIGH-WALL SYSTEM OWNER'S MANUAL [PDF] (2016) Size 09-36
    Excerpt:

    The high wall fan coil unit provides quiet, maximum comfort. In addition to cooling and/or heating, the high wall fan coil unit matched with an outdoor condensing unit will filter and dehumidify the air in the room to provide maximum comfort.
  • ICP FXM4X3600A1 HEATING & COOLING MANUAL [PDF] (at Sears Parts Direct Website) INSTALLATION INSTRUCTIONS Fan Coils FEM4X, FSM4X, FSU4X, FXM4X - local backup copy saved as ICP-Sears-FEM-FSM-FSU-FXM-Manual.pdf

    Excerpt: Model FSU4X is designed for upflow installation, and can be field modified for downflow and horizontal left or right applications (accessory kits required for downflow or horizontal).

    FEM4X and FXM4X models are available for system sizes 1-1/2-5 tons (18,000 - 60,000 BTUH) nominal cooling capacity.

    FSM4X, and FSU4X models are available for system size 5 ton (60,000 BTUH) nominal cooling capacity.

    FEM4X and FXM4X models use an ECM motor and have a factory installed and appropriately sized hard shut-off TXV metering device and are for R-410A refrigerant ONLY.

    FSM4X and FSU4X models use a PSC motor and have a factory installed and appropriately sized hard shut-off TXV metering device and are for R-410A refrigerant ONLY.

    Factory approved electric heater packages are available in sizes 3kW through 30kW. See Product Specification literature for available accessory kits.
  • ICP Tempstar Heil VENT DRAIN KIT NAHA001DK for Multi-Position GAS FURNACES [PDF] (2003) used on N9MP1, N9MP2, *9MPD, *9MPT & *9MPV Multi Position Gas Furnaces.

...

ICP Heil Tempstar HVAC Error & LED Status Codes

Below is an example of Heil or ICP HVAC Error or Status Codes, excerpted from the ICP N80ESN IO MANUAL [PDF]

[Click the image below for a larger view]

Common ICP / Heil LED Flash Error Codes

Watch out: leave power on while reading an error code or counting LED flashhes on HVAC equipment as turning off power will reset the error code display.

ICP Heil Tempstar Common Error Codes
LED Status / Flashes Meaning
OFF No power
ON solid Control Circuit Lockout
Gas valve relay stuck open
Flame sensor circuit failure
Software check error
ON Flashing "heartbeat" rate Normal, no call for heat
Check Thermostat
2 Flashes Pressure switch not open
Failed switch, inducer motor
Blocked air intake or exhaust
Pressure tube obstructed
3 Flashes Pressure switch not closing properly
Check vent for missing cap
Check for unusually high wind affecting venting
Bad inducer motor
Bad pressure switch
Insufficient combustion air
Blocked exhaust vent
4 Flashes Limited circuit open
Possible flame rollout
Blocked exhaust vent
Loose or damaged blower wheel
High wind
Dirty air filter
Blower not working
5 Flashes Flame sensed but gas valve off
Bad gas valve or bad control board
6 Flashes

Weak or no flame
Bad flame sensor or lost electrical ground
Bad igniter
Bad gas valve
Bad gas regulator

7 Flashes Limited circuit lockout
Flame rollout lasted more than 3 minutes
(Control auto-resets after 3 hours)
8 Flashes

Gas heat lockout wont reset
Bad flame sensor
Bad igniter
Bad gas valve or regulator
Check gas or control valve wiring

10 Flashes Reversed polarity
1 Flash then 2 Flashes Blower starts on fire-up
(Too early)
6 Flashes then 1 Flash Ignition lockout
(Control auto-resets after 3 hours)


Notes to the table above

Three quick and easy troublehshooting steps that may clear several of these ICP or Heil or Tempstar error codes:

  1. Try turning power off for 30 seconds to a minute, then turn power back on.
  2. Be sure the room thermostat is callign for heat.
  3. Replace the air handler's air filter

...

ICP Inter-City Products Corporation Contact & Manuals

Inter City Products furnace logo - at InspectApedia.com

This ICP - Inter-City Products Corp. is a separate company from International Comfort Products company - that ICP company's information is given above on this page.

  • Contact: Inter-City Products Corporation, Lavergne, TN USA 37086 or

    Inter City Products Corporation, 650 Heil Quaker Avenue; Lewisburg, TN 37091 USA Tel: (931) 359-3511
  • An Inter-City Products Heater Age Decoder or serial number decoder is found

    at ANTHES BOILER AGE MANUALS & PARTS GUIDES

ICP Inter-City Products Heater Manuals

...


ADVERTISEMENT



Reader Comments, Questions & Answers About The Article Above

Below you will find questions and answers previously posted on this page at its page bottom reader comment box.

Reader Q&A - also see RECOMMENDED ARTICLES & FAQs

Where can I find an International Oil Burner Co Furnace Manual for an old ICP TAC series oil furnace?

I am looking for a manual, or any info really, for a very old International Oil Burner Co Furnace Series TAC 1050. Any info on this?

I can't find anything online. Thank you! On 2023-08-21 by Max

by InspectApedia Publisher

@Max,

To get to the history of the International Furnace brand, in the Comment Box at the end of this page, please post a photo of your furnace data tag and another (one photo per comment) of the furnace itself and we can do some further research for you.

Or at

ECR INTERNATIONAL BOILERS HVAC AGE MANUALS CONTACT

Thanks


Looking for ICP furnace wiring diagram

Looking for a wiring diagram for a ICP furnaces ntg3050fbg1

On 2022-03-16 by Chris White -

Reply by Moderator

In the Recommended Articles near the bottom of our home page for this topic

at HVAC MANUALS, PARTS, & WIRING DIAGRAMS

you will see a link for

MANUALS & PARTS GUIDES - HVAC Brands F-I

That page will have a link to our page on ICP Furnaces & ICP Furnace manuals - please take a look.

There you'd see that the ICP page is at

ICP MANUALS & PARTS GUIDES - HVAC

and scrolling down that page to the list of ICP manuals

you'll find

ICP NT & ND FURNACE INSTALLATION MANUAL [PDF] (2002) Models: NTG3/FBF & NTC6/GNE NTN3/NBF & NTN6/NNE NDN3/NDF & NDN6/GDE

So you can go grab that free PDF download immediately, but for you and other readers, I wanted to show how to find a manual in our HVAC manuals library.



Question: Get the manual for ICP PHD460000k000F1 and for an Inter City Style BUA60A, MFR # NBCM060XKB2

Cannot find ICP PHD460000k000F1 - Mike dickinson · 2021-05015

Hi. I have an Inter City Style BUA60A, MFR # NBCM060XKB2. No diagrams, etc. Can you tell me where I can find this information, since the furnace has begun acting up and will no longer heat. - On 2019-12-30 by Tracer

Moderator reply:

@Mike dickinson,

Mike: You can find PDF downloads of manuals for your ICP PHD-series unit above on this page.

Tracer: if you can post a photo of the data tag on your old Inter City BUA I'll see what else we can fince besides what's already above on this page.


...
